High Speed CNC Angle Drilling and Marking Machine Line for Angle Steel Tower
Applicable Industry:The machine is the special equipment used for angle steel drilling & marking mainly in the field of angle steel tower industry.
Product Composition:
The production line is composed of infeed transfer table unit, rotating loading unit, feeding conveyor unit, marking unit, two drilling units, outfeed conveyor unit, hydraulic system and electrical control system etc.
Product feature:
Specifications:
| Model | JNC2532G3 |
| Angle size(mm) | 125×125×10～250×250×35 |
| Max. length of raw material (m) | 14 |
| Max. length of finished angle (m) | 14 |
| Marking force(kN) | 1200 |
| Marking unit type | Close type |
| No. of character group | 1 |
| No. of character | 18 |
| Character size (mm) | 14×10×19 or 20×12×19 |
| Range of stadia (back mark)(mm) | 50～220 stepless |
| No. of drill on each side | 3 |
| Max. drilling diameter (mm) | 40 |
| Taper of drilling spindle | BT40 |
| Stroke of Spindle(mm) | 140 |
| Max. Spindle rotation speed(r/min) | 6000 |
| Max. feeding speed of drilling head(m/min) | 14 |
| Programming mode | Input by keyboard, RS232 interface, floppy disk and USB interface |
| No. of CNC axes | 9 |
| Overall dimensions(m) | 34.5×7.5×2.5 |
| Machine weight (kg) | ≈30000 |
Main Components:
| No. | Name | Brand |
| 1 | Servo Motor | France Schneider |
| 2 | Servo Driver | France Schneider |
| 3 | PLC | France Schneider |
| 4 | Precision Spindle BT40 | Taiwan KENTURN |
| 5 | Spindle motor | France Schneider |
| 6 | Computer | China Lenovo |
| 7 | Buttons | France Schneider |
| 8 | Disconnector | France Schneider |
| 9 | Transducer | France Schneide |
| 10 | Contactor switch | France Schneide |
| 11 | Main hydraulic valve | Italy Atos |
| 12 | Proximity Switch | France Schneide |
